External 50A thermoswitch simultaneously performs the functions of a fuse and a switch
OSCULATI EXTERNAL THERMAL SWITCH 50A
Resettable and detachable via a special lever, they simultaneously perform the functions of fuse and switch.
Manufactured in accordance with USA SAEJ1171 and CE 28846 “Vapor Proof” standards, capacity 3000 intervention cycles.
Permitted voltage: max 48 V, Increased version, 5/16” electrical terminals
(instead of 1/4”) to make it easier to connect cables.
The flush-mounted model requires a simple circular hole for installation. IP66 Weatherproof.
From 100A to 200A it can also be used as a general battery switch.
Maximum voltage capacity: 5000A 14VDC; 3000A 28VDC; 1500A 48VDC.
Operating temperature: -40C° / 85C°.
UM: PZ
Height: 7 cm
Weight: 0.22 kg
Width: 9 cm
Volume: 378 cm³
Length: 6 cm
