OSCULATI FLUSH-MOUNTED THERMO SWITCH 50A

Resettable and detachable via a special lever, they simultaneously perform the functions of fuse and switch.

Manufactured in accordance with USA SAEJ1171 and CE 28846 “Vapor Proof” standards, capacity 3000 intervention cycles.

Permitted voltage: max 48 V, Increased version, 5/16” electrical terminals

(instead of 1/4”) to make it easier to connect cables.

The flush-mounted model requires a simple circular hole for installation. IP66 Weatherproof.

From 100A to 200A it can also be used as a general battery switch.

Maximum voltage capacity: 5000A 14VDC; 3000A 28VDC; 1500A 48VDC.

Operating temperature: -40C° / 85C°.

UM: PZ

Height: 7 cm

Weight: 0.15 kg

Width: 9 cm

Volume: 378 cm³

Length: 6 cm
